OLED Display showing Crimping Time, Electricity Quantity, Maintenance Reminding and Fault Code

• Crimping head rotates 350°
• Two stage hydraulic system with fast feed and power control
• Quick motor stop guarantees highest safety for the operator
• Automatic retraction when crimp is completed
• Electronic control and monitor of crimping operation
• Ergonomic design and optimized position of center of gravity
• Rated pressure: 120kN
• Oil capacity: 160ml
• Stroke: 42mm
• 5 – 8 seconds per cycle time
• Max crimping: Copper 400mm² / Aluminium 300mm²
• **Please note: When selecting die sizes for copper and aluminium, you will use the same dies but reduce the size by one when switching from copper to aluminium. For example, if you are using a 240 mm² die for copper, you would use a 185 mm² die for aluminium.
